Description

EXCEEDCONN – CABLE CONNECTOR MALE (EP050-1224-00)

Manufacturer: Exceedconn

Product name: Cable Connector Male

Model: EP050-1224-00

Series: EP-Connector

Order no.: 910001803



General Information: EXCEEDCONN – CABLE CONNECTOR MALE (EP050-1224-00)

Connector Type: Male waterproof cable connector

Number of Pins: 5 Pins

Protection Rating: IP68

Rated Current: 15 A

Rated Voltage: 450 VAC

Material: Polyamide, copper, nickel-plated

Operating Temperature: -40°C to +85°C

Solid Cable Size: 0.5–1.5 mm²

Flexible Cable Size: 1.0–1.5 mm²

Screw Size: M2.5

Recommended Tightening Torque: 0.6 Nm

Cable Seals Included: 9.5 mm, 11.5 mm, 12.5 mm

Application: Indoor / outdoor use, LED lighting

Compliance / Certification: RoHS, REACH; IP68-rated



Product Features

1.  IP68 waterproof protection for reliable use in wet and dusty environments

2. 5-pin male connector for secure electrical connections

3. Rated up to 15 A / 450 VAC

4. Suitable for indoor and outdoor applications

5. Wide operating temperature range from -40°C to +85°C

6. Durable construction using polyamide, copper, and nickel-plated components

7. Supports both solid and flexible cables

8. Screw-crimped connection for stable and secure cable termination

9. Supplied with multiple cable seals: 9.5 mm, 11.5 mm, and 12.5 mm

10. Suitable for applications such as LED lighting and industrial electrical connections

11. Compact design for easy installation and maintenance
